X Travel : 6,000 mm
Y Travel : 2,100 mm
Z Travel : 760 mm
Spindle Taper : BT#50 (ISO 50) /DIN69871 A (Opt.)
Max
Spindle Speed : 10 ~ 6,000 (Std.) 10 ~ 8,000 Direct Driven (Opt.)
Spindle Motor : 22 /26 ( 30 / 35 Opt.) Kw ( con. / 30 min. )
Tool Changer : 32 (60, 90, 120 Opt.)
Machine Weight 45,000 Kg
|
Through sustainable operation over the past two decades, Awea has established a comprehensive management system integrated with research, designing, manufacturing, assembling, testing, monitoring, sales and services. Globally, Awea is an extensively certified company passing ISO 9001, ISO 14001 and CE and so on. Domestically, Awea is not only a highly awarded company but also one of few machine tool companies listed on the Taiwan Stock Exchange. |
LP Series
Models |
LP-3021 |
LP-5021 |
LP-6021 |
LP-4025 |
Max. X axis
travel |
3,000 mm |
5,000 mm |
6,000 mm |
4,000 mm |
Max. Y axis
travel |
2,100 mm |
2,100 mm |
2,100 mm |
2,500 mm |
Max. Z axis
travel |
760 Std. (1,000. 12,000, 14,000 Opt.) |
760 Std. (1,000. 12,000, 14,000 Opt.) |
760 Std. (1,000. 12,000, 14,000 Opt.) |
760 Std. (1,000. 12,000, 14,000 Opt.) |
Dist. from
spindle nose
to table |
240 ~ 1000 ( 200, 1200, 200 ~ 1400 : 200 ~ 1600 Opt.) |
240 ~ 1000 ( 200, 1200, 200 ~ 1400 : 200 ~ 1600 Opt.) |
240 ~ 1000 ( 200, 1200, 200 ~ 1400 : 200 ~ 1600 Opt.) |
240 ~ 1000 ( 200, 1200, 200 ~ 1400 : 200 ~ 1600 Opt.) |
Spindle center
~ table (X, Y) |
3,020 mm / 1,000 mm |
5,020 mm/ 1,100 mm |
6,320 mm |
4,020 mm |
| Spindle Speed Range |
6,000 rpm (Std.), 8,000 rpm Direct Driven Opt. |
Spindle motor
output |
11 / 15
( 22 /26 Opt.) Kw ( con. / 30 min. ) |
| Spindle taper |
BT#50 (ISO 50) /DIN69871 A (Opt.) |
| Cutting Feedrate |
1 ~ 10,000 mm/min |
1 ~ 10,000 mm/min |
1 ~ 10,000 mm/min |
1 ~ 10,000 mm/min |
X / Y / Z axes
rapids |
20 / 20 / 20
m / min |
20 / 20 / 20
m / min |
(20,20,15) / 20 / 10
m
/ min |
Max. tool
diameter /
Adjacent |
Ø125 mm /
Ø215 mm |
Ø125 mm /
Ø215mm |
Ø127 mm /
Ø215 mm |
Ø127 mm /
Ø215 mm |
Tool magazine
capacity |
30 (40 Opt.) |
32 (60, 90, 120 Opt.) |
| Machine weight |
17,000 Kg |
20,000 Kg |
19,000 Kg |
28,000 Kg |
|
|
