Ecoca MT-310


X Travel :225 mm
Z Travel :510/760/1010 mm
Spindle Speed : 4200 rpm
Spindle Motor : 15/18.5 KW (18.5/22KW opt.)
Guideways : Hard Rail

Download PDF Ask A Quote


Ecoca MT-310


MT Series

ITEM MT-308MCS MT-310/310MC MT-312/312MC
SWING OVER BED
600 mm 600 mm 600 mm
OVER CROSS SLIDE
400 mm 400 mm 400 mm
MAX. TURNING DIA
345 mm 450 mm 330 mm 450 mm 330 mm
MAX. WORK LENGTH
750 mm 490/740/990 mm 480/730/980 mm
DRAW TUBE DIA
52 mm 75 mm 91 mm
CHUCK SIZE
8" 10" 12"
SPINDLE DRIVE MOTOR
9/11(main),5.5/7.5(sub) KW 15/18.5 KW (18.5/22KW opt.) 15/18.5 KW (18.5/22KW opt.)
SPINDLE SPEED RANGE
4800 rpm 4200 rpm 3200 rpm
SPINDLE NOSE
A2-6 ASA A2-8 ASA A2-8 ASA
THROUTH SPINDLE HOLE DIA
62 mm 90 mm 102 mm
FRONT BEARING DIA
100 mm 130 mm 140 mm
SPINDLE TAPER
1/20 1/20 1/20
MCS SUB SPINDLE SPEED
6000 rpm - -
MCS SUB SPINDLE NOSE
A2-5 ASA - -
MCS SUB SPINDLE TRAVEL
700 mm - -
MCS SUB MILLING SPEED
3800 rpm 3800 rpm 3800 rpm
X AXIS TRAVEL

225 mm

225 mm
225 mm
Z AXIS TRAVEL
770 mm 510/760/1010 mm 500/750/1000 mm
B AXIS TRAVEL
670 mm  -  -
X AXIS MOTOR
3.0 KW/3.8 HP 3.0 KW/3.8 HP 3.0 KW/3.8 HP
Z AXIS MOTOR
3.0 KW/3.8 HP 3.0 KW/3.8 HP 3.0 KW/3.8 HP
B AXIS MOTOR
3.0 KW/3.8 HP - -
X AXIS RAPID TRAVERSE
20 20 20
Z AXIS RAPID TRAVERSE

20

20

20
B AXIS RAPID TRAVERSE
20 - -
GUIDEWAYS
HARD RAIL HARD RAIL HARD RAIL
NO. OF TOOL STATIONS
12 12 12
SIZE OF EXTERNAL TURNING TOOL
25 mm 25 mm 25 mm
BORING BAR DIA
40 mm 40 mm 40 mm
QUILL DIA
90 mm 90 mm 90 mm
QUILL TRAVEL
120 mm 120 mm 120 mm
TAILSTOCK TRAVEL
810 mm 560/810/1060 mm 560/810/1060 mm
QUILL TAPER
MT#5 MT#5 MT#5
ELECTRICAL POWER SUPPLY
30 KVA 30 KVA 40 KVA
COOLANT TANK CAPACITY
150 Liter 150 Liter 150 Liter
COOLANT FLOW
20 L/min 20 L/min 20 L/min
TO TAL HEIGHT
1905 mm 1905 mm 1905 mm
FLOOR SPACE

4300 L

2100 W

3900/4300/4700 L

2100 W

3900/4300/4700 L

2100 W
NET WEIGHT
5300 kg 4800/5300/5800 kg 4900/5400/5900 kg
